5L hot melt adhesive machine

detailed information

Brand: Henghai

Name: 5kg hot melt adhesive machine

Model: aks-5-q2e-a

Temperature control range: 0-200 ℃

Operating temperature: 165 ℃

Rated power: 2000W

Rated voltage: 220VAC

Rated current: 9.1a

Overall weight: 25kg

Overall dimension: 550x330x540 (L x W x H)

Detailed description

※ pre melting type heating melting cylinder, "TEFLON" coating to reduce carbide generation.

※ the grooved self buckle shell is easy to fold and repair, and meets the international design safety standards.

※ glue amount up to 5kg / HR, power: 2000W

※ the digital PID temperature controller cooperates with the K / PT100 temperature sensor to accurately control the temperature to prevent the deterioration and yellowing of hot melt adhesive and the precipitation of silicone oil.

※ equipped with 1 set of durable piston pump, stable and continuous glue delivery and high glue pressure

※ 1 set of return valves and 5 sets of over temperature protection circuits are provided to ensure safety.

matters needing attention

① For high temperature and high pressure equipment, pay attention to prevent scalding and electric shock;

② The equipment can be started only after the temperature is ready;

③ Power off operation shall be conducted during installation;

④ When installing auxiliary equipment such as gun and pipe, the pressure shall be relieved and discharged before installation;

⑤ Clean the dust regularly to prevent static ignition;

⑥ Regularly check whether there is glue leakage and electric leakage.

Scope of application

Application fields: paper packaging, box sealing, automobile manufacturing, electronic and electrical packaging, trademark labeling, composite materials, maternal and child health products, medical mattresses, etc
