High speed compensation control system

Detailed information
Brand: alcos
Name: rubber machine high speed compensator
Model: AKS-1224KZ
Input voltage: 220VAC
Output voltage: 24VDC
Output points: 12
Output analog quantity: 4 channels x 1-10vdc
Weight: 2.8kg
External dimension: 375x160x240 (L x W x H)
Detailed description
Output points are 12
0-10V voltage tracking
Low speed start control function
Output angle can be adjusted during operation
☆ origin offset function
Automatic front and rear compensation function
Communication function
Password protection function
Display in Chinese / English
Speed mutual aid function
It can meet the high-speed intermittent compensation of the production line, with the maximum action frequency of 1000 times / min.
Matters needing attention
① after the temperature is ready, the equipment can be started
② power off operation is required during installation;
③ clean the dust regularly to prevent static electricity from igniting;
④ regularly check whether there is leakage.
Application scope
Application fields: paper packaging, box sealing, automobile manufacturing, electronic and electrical packaging, trademark labeling, material compounding, maternal and child health products, medical mattresses, etc. equipped with various brand models of glue machines to accurately control the glue amount and glue position.
For more information, please visit www.hhaks.com
